Model: 4V210-08

Position and way NO.: 2/5 way

Operating pressure: 0.15~0.8MPa

Max.proof pressure: 1.2MPa

Allowable voltage: ±10% of rated voltage

Power consumption: 5.5VA

Voltage: 220VAC

Waterproof: IP65

The Pneumatics System

A generic air pneumatic system consists of an air compressor, valve(s), pneumatic cylinder(s), amplifier, and feedback module. There are different types of pneumatic cylinders. Pneumatic cylinders can also be called pneumatic actuators.

When choosing a pneumatic actuator, be aware of the bore, stroke, and rod diameter. Also, you want a double acting cylinder. It is recommended to purchase all your pneumatic parts from the same brand so that the tubing and connections will be compatible with each other.

The bore is the overall diameter (measured in inches) of the pneumatic cylinder. The stroke is the length that the cylinder can fully extend. The rod diameter is the measurement (in inches) of the shaft of the cylinder.
